Panasonic AW-UE40

Brand:

La AW-UE40 ha un corpo compatto di nuova concezione con un peso di soli 1,8kg, che lo rende molto facile da maneggiare e da installare in qualsiasi tipo di ambiente.

A differenza della UE50, la UE40 ha solo l'HDMI.

4K 25/30p e Zoom ottico 24x
Nuovo sistema Direct Drive per una migliore reattività e silenziosità
Supporta il protocollo NDI|HX

Leggi di più



Visualizza tutte le immagini
2.499,00 €
2.499,00 € Iva escl.
Solitamente in 3-5gg
Colore
DISPONIBILITA': 2gg
Aggiungi ai preferiti
Descrizione

Le telecamere remote migliorano la comunicazione visiva in una varietà di applicazioni che vanno dalle lezioni online ai seminari online. L'AW-UE40 ha un design compatto per mimetizzarsi con l'ambiente circostante e funziona in modo molto silenzioso per consentire un uso flessibile in qualsiasi luogo o condizione di ripresa video.

L'AW-UE40 offre un'elevata sicurezza ed è facile da installare e utilizzare per acquisire immagini stabili, quindi anche le persone che non hanno familiarità con le riprese video o il funzionamento della fotocamera possono utilizzarlo. L'eccellente flessibilità del prodotto semplifica il cablaggio e il funzionamento. È possibile il collegamento con il software per conferenze online o l'applicazione online, quindi lo streaming video online è facile da avviare.

L'AW-UE40 è un modello standard perfetto per le persone che desiderano utilizzare lo streaming video online più frequentemente o migliorarne la qualità.

Fornisce un ambiente ibrido stabile per la connessione online e offline

  • Risoluzione 4K, grandangolo e zoom ad alto ingrandimento per offrire "l'atmosfera della sala".
  • Software di tracciamento automatico per seguire e catturare in modo affidabile l'oratore.
  • Protocollo di streaming sicuro e stabile per ridurre il rischio di problemi di comunicazione.
  • Riproduzione fluida di video di alta qualità.


Dimensioni e silenziosità dell'unità per un utilizzo flessibile in qualsiasi sito di riprese video

  • Il design compatto a forma di cupola si fonde con l'ambiente circostante. Il peso leggero e le dimensioni ridotte offrono una maggiore flessibilità nell'installazione della telecamera.
  • Il suono di funzionamento silenzioso consente l'uso della fotocamera in qualsiasi situazione.
  • Lo stabilizzatore d'immagine garantisce riprese video stabili.


Eccellente flessibilità del sistema per ottenere un cablaggio intelligente e un funzionamento regolare

  • Facilità di installazione e funzionamento anche per personale inesperto o personale ridotto.
  • Un singolo PC o controller può gestire e controllare più telecamere.
  • Utilizzare come una fotocamera USB.
  • Può caricare video direttamente sul servizio di streaming live.
Leggi di piùShow less
Dettagli del prodotto
AW-UE40
Risoluzione sensore
8,5 MP
Tipo sensore
1/2.5 - 4K MOS
Zoom
24x
Video I/O
HDMI OUT
Specifiche Tecniche
Comprehensive
Power Requirements 12 V DC (10.8 V to 13.2 V) (Supplied AC adapter)
PoE+ IEEE802.3at compliant : DC42 to 57 V (Camera Input)
(Software authentication (LLDP) is supported)
Current Consumption 1.8 A (Supplied AC adaptor), 0.6 A (PoE+ power supply)
Ambient Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Allowable Humidity Ranges 20 C to 90 C (no condensation)
Storage Temperature -20 °C to 50 °C (-4 °F to 122 °F)
Mass Approx. 1.8 kg (3.97 lbs) (excluding ceiling mounting bracket)
Approx. 2.05 kg (4.52 lbs) (including ceiling mounting bracket)
Dimensions (W x H x D) 160.0 mm x 192.1 mm x 166.0 mm
(6.299 inches x 7.563 inches x 6.535 inches)
(Excluding protrusions, cable cover, ceiling mounting bracket)
Finish AW-UE50W/AW-UE40W: White
AW-UE50K/AW-UE40K: Black
Compatible controllers AW-RP150GJ, AW-RP60GJ, AW-RM50AG, AK-HRP1000*1,2, AK-HRP1005*1,2, AK-HRP1015*2, AK-HRP250*2
Camera part
Image Sensors 1/2.5-type 4K MOS x1
Effective Pixels 8,490,000 pixel
Lens Motorized Optical 24x zoom, F1.8 to F4.0
[f=4.12 mm (5/32 inches) to 98.9 mm (3?29/32 inches);
35 mm (1?3/8 inches) equivalent: 25.0 mm (31/32 inches) to 600.0 mm (23?5/8 inches)]
Zoom ? Optical zoom: 24x
? i.Zoom UHD 28x, FHD 36x
? Digital extender zoom: 1.4x , 2x
Conversion Lens Not supported
Angle of View Range Horizontal angle of view: 74.1° (wide) to 3.3° (tele)
Vertical angle of view: 46.0° (wide) to 1.9° (tele)
Diagonal angle of view: 81.8° (wide) to 3.8° (tele)
Optical Filter Not equipped
Focus Switching between auto and manual
Focus Distance Entire zooming range: 1200 mm (3.9 ft)
Wide end: 100 mm (0.33 ft)
Color Separation Optical System 1MOS
Minimum Illumination 3 lx (F1.8, 59.94p, 50IRE, 42 dB, without accumulation)
Horizontal Resolution UHD: 1,500 Typ (Center area)
FHD: 1,000 Typ (Center area)
Gain Selection Auto, 0 dB to 36 dB*3 (Super Gain function equipped : 37 dB to 42 dB)
Frame Mix Auto, 0 dB, 6 dB, 12 dB, 18 dB, 24 dB*4
Electronic Shutter Speed 59.94p/59.94i 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
29.97p 1/30, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
23.98p/24p 1/24, 1/48, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
50p/50i 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
25p 1/25, 1/50, 1/60, 1/100, 1/120, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/8000, 1/10000
Synchro Scan 59.94p/59.94i 60.0 Hz to 7200 Hz
29.97p 30.0 Hz to 7200 Hz
23.98p/24p 24.0 Hz to 7200 Hz
50p/50i 50.0 Hz to 7200 Hz
25p 25.0 Hz to 7200 Hz
Gamma HD / Normal / Cinema1 / Cinema2 / Still Like
White Balance ? ATW : 3200 K, 5600 K (ATW Speed 3-stage variables.)
? AWB : AWB-A / AWB-B
? VAR (selectable between 2000 K and 15000 K by designating a value)
Chroma Amount Variability OFF, -99 ? to 99 %
Scene File Full Auto, Scene1, Scene2, Scene3
Output Format SDI

* AW-UE50W/K only

HD 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native),
23.98p (over59.94i), 1080/29.97psF, 25psF, 23.98psF, 1080/24p (Just),
23.98p (Native), 720/59.94p, 50p
HDMI 4K 2160/29.97p (Native), 2160/25p (Native), 2160/24p (Just), 2160/23.98p (Native)
HD 1080/59.94p, 50p, 1080/59.94i, 50i, 1080/29.97p (Native), 25p (Native),
23.98p (over59.94i), 1080/24p (Just), 23.98p (Native), 720/59.94p, 50p
Input
Input Connector DC 12 V IN
Output
Video Output HDMI HDMI 1.4 connector
4:2:2/10bit
? HDCP is not supported.
? Viera Link is not supported.
3G-SDI OUT

* AW-UE50W/K only

SMPTE292M, 424M/ 75 ? (BNCx1)
? Level-A/Level-B supported
Input/output
Input/Output Connector LAN LAN terminal for IP control (RJ-45)
RS-422 CONTROL IN RS422A (RJ-45)
USB USB2.0 DEVICE, Type C connector, no USB bus-powered function.
Only compatible with UVC (USB Video Class)

* UVC 1.0, UAC 1.0

MIC/LINE input
(SDI/HDMI/IP)
AAC compatibility (compatible with IP only)
?3.5 mm stereo mini jack
? During MIC input
Input level: -40 dBV (0 dB=1 V/Pa, 1 kHz)
Supply voltage: 2.5 V±0.5 V (plug-in power compatible)
"? Input impedance: Approx. 2 k? (when plug-in power is turned ON)
Approx. 20 k? (when plug-in power is turned OFF)"
? During LINE input
Input level: -10 dBV
Input impedance: Approx. 3 k?
? Input volume variable range: -36 dB to 12 dB (3 dB step)
? Embedded audio output level: -12 dBFS
? Sampling frequency: 48 kHz
Pan-tilt Head Unit
Camera/Pan-tilt Head Control IP connecting cable ? If you have a PoE+ ethernet hub
LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft)
? If you don't have a PoE+ ethernet hub
LAN cable*5 (category 5e or above, straight cable) Max 100 m (328 ft)
AW protocol connecting cable ? LAN cable*5 (category 5e or above, straight cable) Max 1000 m (3280 ft)
Installation Method Stand-alone (Desktop) or suspended (Hanging)*6
Pan/tilt Operation Speed Speed range: 0.08°/s to 60°/s (Normal mode)*7
? 3 speed modes installed
Normal: 60°/s, Fast1: 90°/s, Fast2: 180°/s
Panning Range ±175°
Tilting range -30°to 90°*8
Quietness NC25 or less
Supported Operating Systems and Web Browsers Windows*9 Windows 10
Windows® Internet Explorer® 11 (32 bit / 64 bit)
Microsoft Edge
Google Chrome
Mac*9 Mac OS v11.0.1 / Safari 14.01
Mac OS v11.0.1 / Google Chrome
Mac OS v10.15 / Google Chrome
Mac OS v10.14 / Google Chrome
iPhone / iPad iOS
Safari
iPadOS
Android Android OS
Google Chrome
IP Streaming
Image Streaming Mode JPEG (MJPEG), H.264, H.265, NDI®|HX version 2*10,11,12,13 (H.264)
Image Resolution 1920x1080, 1280x720, 640x360, 320x180
Image Transmission Setting JPEG Frame rate: Maximum 30fps
Image quality (Fine / Normal)
H.264 Transmission Type Unicast port (AUTO)
Unicast port (MANUAL)
Multicast port
Transmission Priority Constant bit rate
Frame rate
Best effort
Frame Rate [60 Hz] 5fps / 15fps / 30fps / 60fps
[50 Hz] 5fps / 12.5fps / 25fps / 50fps
Max Bit Rate 512kbps / 768kbps / 1024kbps / 1536kbps / 2048kbps /3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps /12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps
H.265 Transmission Type Unicast port (AUTO)
Unicast port (MANUAL)
Multicast port
Frame Rate [60 Hz] 30fps / 60fps
[50 Hz] 25fps / 50fps
Max Bit Rate 1024kbps / 1536kbps / 2048kbps / 3072kbps / 4096kbps / 6144kbps / 8192kbps / 10240kbps / 12288kbps / 14336kbps / 16384kbps / 20480kbps / 24576kbps
Audio Compression Type AAC-LC, 48 kHz / 16 bit / 2ch
Supported Protocols IPv6 TCP/IP, UDP/IP, HTTP, HTTPS, DNS, NTP, DHCPv6, RTP, MLD, ICMP, ARP, RTMP, SRT
IPv4 TCP/IP, UDP/IP, HTTP, HTTPS, RTSP, RTP, RTP/RTCP, DHCP, DNS, DDNS, NTP, IGMP, ICMP, ARP, RTMP, RTMPS, SRT
NDI® Support
NDI Support NDI®|HX version 2 : Available to upgrade
Image Resolution (NDI®|HX) 1920x1080, 1280x720
Image Transmission Setting NDI®|HX version 2 Transmission Type TCP/UDP
Unicast/Multicast
Audio Compression Type NDI®|HX version 2 AAC-LC, 48 kHz, 16 bit, 2 ch
New functions
F-number display Displayed on the AW-RP150GJ and AW-RP60GJ sides
Menu display on IP video Supported*14
Powe LED ON/OFF control
Tripod screw penetration measures Possible
Pan/tilt mechanical method New Direct Drive System
Image Stabilization MENU switching: Select between Off/O.I.S.
Privacy Mode The lens surface faces backward when standing by (ON/OFF)

* Default is OFF

Other functions
Tally LED Display Color red / green

  • *1: Discontinued Model
  • *2: Will be supported in the future
  • *3: Can be set in 1 dB step increments.
  • *4: Cannot be set when the format is 2160/29.97p, 2160/23.98p, 2160/24p, 2160/25p, 1080/29.97p, 1080/23.98p (59.94i), 1080/29.97PsF, 1080/23.98PsF, 1080/25p, 1080/25PsF.
  • *5: STP (Shielded Twisted Pair) is recommended.
  • *6: To ensure safety, the unit must be secured using the mount bracket supplied.
  • *7: Note that the operating noise may be loud in high speed. If the operating noise is disturbing, use the Normal mode.
  • *8: The main unit may appear in the video depending on the pan/tilt position.
  • *9: Supported OS indicated are for browsers current as of September 2021. See ?Service and Support / PASS? for the latest information on browser support.
  • *10: NDI® is a new protocol developed by NewTek, Inc. that supports IP video production workflow.
  • *11: NDI® is a registered trademark of NewTek, Inc. in the United States and other countries.
  • *12: In this instance, NDI®|HX is used to indicate high efficiency low bandwidth NDI®|HX. In the NDI®|HX mode, 4K video signals cannot be output. AW-UE50/AW-UE40 supports NDI®|HX version 2 and Full HD output.
  • *13: For details, please contact a sales representative of Panasonic. To use NDI®|HX, the driver must be installed and activated.
  • *14: Non-synchronous with SDI-OUT
